Description
A programmable non-medical sensor designed for measuring ECG, heart rate, and movement with customization and branding opportunities. This sensor runs on an open API, allowing the development of use-case-specific on-device apps for customers’ own solutions.
The kit includes free access to Movesense developer tools, sample code, and documentation.
Developed, designed and manufactured in Finland.
Kit contents
- Movesense HR+ sensor
- Accessories
- 1 pcs Heart Rate Monitor Belt with Movesense connector (black, size M)
- 1 kit of ECG Glue-on Patch Electrode (2 x ECG patch)
- 1 pcs Movesense Wrist Mount
- 1 pcs Movesense Clothing Clip
- 1 pcs Movesense Surface Mount
Please contact sales@movesense.com for business inquiries.
Technical highlights
- 9-axis movement sensor: 3 x accelerometer,
3 x gyroscope, 3 x magnetometer - Single channel non-medical ECG, Heart rate, R-R intervals
- 1-wire extension bus interface through Movesense connector
- In-built memory for logging data
- Bluetooth® Smart compatible
- Software tools for developing applications that run on the sensor
- Wireless firmware update with BLE
- Water (IP68) and shock proof construction
- Low profile snap connection for attaching the sensor to apparel and gear
- User replaceable battery (CR2025 coin cell)
- Battery life optimization options through software
Dimensions
- Diameter: 36,6 mm (1.44 in), Thickness: 10,6 mm (0.42 in)
- Weight 10 g / 0.35 oz with battery
- Water resistant to 30 m/100 ft
MCU
- Nordic Semiconductor nRF52832 comprising 32 –bit ARM® Cortex®-M4 with 64 kB on-chip RAM and 512 kB on-chip FLASH
- Integrated Bluetooth Low Energy radio, 2,4 GHz
- External memory: 3 Mb (384 kB) EEPROM
Sensors
- Accelerometer/gyro combo with the following dynamic ranges:±2/±4/±8/±16 g full scale, ±125/±245/±500/±1000/±2000 dps full scale
- Magnetometer with ±50 gauss dynamic range
- Temperature with the following maximum ratings/accuracy:±0.5°C (max) from 0°C to +65°C±1.0°C (max) from –40°C to +125°C
I/O
- Bluetooth Smart
- Led (red) on the front
- UART, debug I/F and power & ground (behind the battery slot/sticker)
Energy source
- CR 2025 lithium coin cell battery
Software
- Easy to use C++ Movesense Device API
- iOS and Android libraries with firmware update capability
- GNU tool chain for embedded ARM
Approvals and compliances
- CE, FCC, IC
- Conforms REACH, RoHS
- Bluetooth 4.2 / 5.0
Patents
- US 13/071,624, US 13/832,049, US 13/832,598, US 13/917,668, US 13/397,872, USD 667,127, US 8,386,009, US 8,750,959, US 8,814,574, US 8,886,281, others pending
At this point the Movesense Developer kit is available for business customers only.
